General Information
Manufacturer: Honda
Model Year: 2024
Model: FourTrax Foreman Rubicon 4×4 EPS
Model Code: TRX520FM6R
Stock Number: 900039
Color: Honda Phantom Camo
Brakes/Wheels/Tires
Brakes
Front – Dual 190 mm discs
Rear – Dual 170 mm discs
Tires
Front – 25 x 8-12
Rear – 25 x 10-12
Drivetrain
Transmission: Five-speed automatic dual-clutch with reverse and Low / Drive sub-transmission
Drive System: 4×4
Drive: Direct front and rear driveshafts with TraxLok® and locking front differential
Engine
Engine: Four-stroke, OHV; two valves per cylinder, longitudinally mounted
Cooling: Liquid
Cylinders: Single
Displacement: 518 cc
Bore x Stroke: 96.0 x 71.5 mm
Compression Ratio: 9.5:1
Clutch: Automatic
Fuel System: Programmed fuel injection (PGM-FI); 36 mm throttle body
Emissions: Meets current EPA off-road emissions standards
Starting: Electric with optional auxiliary recoil
Fuel Capacity: 3.9 gal. including 1.3 gal. reserve
Operational
Suspension
Front – Independent double-wishbone; 7.3 in. travel
Rear – Independent dual-arm; 8.5 in. travel
Towing Capacity: 1,322 lb.
Capacity
Front rack – 99 lb.
Rear rack – 187 lb.
Warranty: One year, transferable, limited
